REGUFOAM® Vibration 990plus
Download Our Data Sheet

REGUFOAM® Vibration 990plus

Forms of delivery

Rolls, ex warehouse
Thickness: 12.5 and 25 mm
Length: 1,500 mm
Width: 1,000 mm

Customized strips and pads, self-adhesive versions and special roll lengths available on request.

Technical details

Maximum static load bearing capacity
2.500 N/mm²

Maximum dynamic load bearing capacity for intermitted loadings
0 to 3.500 N/mm²

Rare, short term peak loads
up to 8.000 N/mm²

Physical propertyNormResultComment
Static modulus of elasticityBased on EN 82620.0 - 78.0 N N/mm²Tangential modulus, see figure “Modulus of elasticity”
Dynamic modulus of elasticityBased on DIN 5351341.0 - 160.0 N/mm²Depending on frequency, load and thickness,see figure “dynamic stiffness“
Mechanical loss factorDIN 535130.09Load-, amplitude- and frequency-dependent
Compression setBased on DIN EN ISO 18568.6%Measured 30 minutes after decompression with 50% deformation / 23 °C after 72 hrs
Tensile strengthBased on DIN EN ISO 17986.9 N/mm²
Elongation at breakBased on DIN EN ISO 1798190%
Tear resistanceBased on DIN ISO 34-134.5 N/mm
Fire behaviourDIN 4102
DIN EN 13501-1
B2
E
Sliding frictionREGUPOL-laboratory
REGUPOL-laboratory
0.5
0.6
Steel (dry)
Concrete (dry)
Compression hardnessBased on DIN EN ISO 3386-23640 kPaCompressive stress at 25 % deformation
test specimen h = 25 mm
Rebound elasticityBased on DIN EN ISO 830755%Dependent on thickness,
test specimen h = 25 mm
Force reductionDIN EN 1490420%Dependent on thickness,
test specimen h = 25 mm
