Forms of delivery
Rolls, ex warehouse
Thickness: 12.5 and 25 mm
Length: 1,500 mm
Width: 1,000 mm
Customized strips and pads, self-adhesive versions and special roll lengths available on request.
Technical details
Maximum static load bearing capacity
0.850N/mm²
Maximum dynamic load bearing capacity for intermitted loadings
0 to 1.200 N/mm²
Rare, short term peak loads
up to 7.000 N/mm²
| Physical property | Norm | Result | Comment |
|---|---|---|---|
| Static modulus of elasticity | Based on EN 826 | 5.4 - 8.0 N/mm² | Tangential modulus, see figure “Modulus of elasticity” |
| Dynamic modulus of elasticity | Based on DIN 53513 | 11.0 - 16.5 N/mm² | Depending on frequency, load and thickness,see figure “dynamic stiffness“ |
| Mechanical loss factor | DIN 53513 | 0.10 | Load-, amplitude- and frequency-dependent |
| Compression set | Based on DIN EN ISO 1856 | 7.9% | Measured 30 minutes after decompression with 50% deformation / 23 °C after 72 hrs |
| Tensile strength | Based on DIN EN ISO 1798 | 4.6 N/mm² | |
| Elongation at break | Based on DIN EN ISO 1798 | 230% | |
| Tear resistance | Based on DIN ISO 34-1 | 20.0 N/mm | |
| Fire behaviour | DIN 4102 DIN EN 13501-1 | B2 E | |
| Sliding friction | BSW-laboratory BSW-laboratory | 0.6 0.75 | Steel (dry) Concrete (dry) |
| Compression hardness | Based on DIN EN ISO 3386-2 | 1241 kPa | Compressive stress at 25 % deformation test specimen h = 25 mm |
| Rebound elasticity | Based on DIN EN ISO 8307 | 58% | Dependent on thickness, test specimen h = 25 mm |
| Force reduction | DIN EN 14904 | 35% | Dependent on thickness, test specimen h = 25 mm |
